1.6 m / 1.9 m dye-sublimation printers — CMYK, constant-tension feeding

HY-1704 / HY-2004 Sublimation Printers

Powered by 4× Epson I3200-A1 in CMYK configuration, the HY-1704/2004 delivers high-throughput sublimation output in 1.6 m / 1.9 m widths. An adjustable carriage (≤8 mm), constant-tension feeding, wide anti-static pinch rollers and front arc pre-heating work with the integrated aluminum cleaning station and ink agitation/circulation to keep prints stable during long runs.
Request a Demo
Download Specifications

Product Features & Benefits

Why Choose H·EASY Sublimation Printing

※ Actual equipment configuration shall prevail.

Quad I3200-A1 Printheads · High-Speed CMYK Printing

4× I3200-A1 in CMYK for real high-speed production.

Transparent Real Productivity

HY-1704 / HY-2004（m²/h）：2p 106/110｜3p 80/85｜4p 53/55｜6p 33/35. Clear throughput to plan shifts and jobs.

Constant-Tension Feeding · Wide Anti-Static Rollers

Constant-tension feeding and wide anti-static pinch rollers keep media flat and tracking true.

Front Arc Pre-Heating · Fast Ink Fixing

Front arc pre-heating promotes even ink laydown for consistent density.

Adjustable Carriage Height ≤8 mm · Versatile Media Compatibility

≤8 mm adjustable carriage height reduces head strikes across media.

Aluminum Beam + Integrated Cleaning Station

Aluminum beam with integrated cleaning station for reliable, low-maintenance runs.

CMYK Throughput · 1.6 m / 1.9 m Wide Format

  • Four I3200-A1 printheads in parallel deliver full coverage across 2/3/4/6-pass modes—from sampling to mass production.
  • Two width options: YF-1704 (1.6 m) and YF-2004 (1.9 m) share the same platform for seamless scalability.
  • 720×1800 dpi resolution ensures clean text edges and smooth color gradients.

Feeding & Heating · Stable Media Handling · Even Ink Laydown

  • Constant-tension feeding with wide anti-static pinch rollers effectively prevents wrinkles and media skew.
  • Front arc pre-heating improves ink spreading; rear heating and cooling fans accelerate drying.
  • Supports media up to 3 mm thick, meeting the needs of most sublimation papers and substrates.
automatic ink supply system
powder feeding system

Uptime & Maintenance · Reliable Structure & Easy Service

  • Integrated aluminum cleaning station ensures tight capping and efficient negative-pressure cleaning with reduced ink waste.
  • Ink agitation and circulation minimize pigment sedimentation and color drift during long production runs.
  • Gigabit Ethernet connection ensures stable data transmission with major RIP software compatibility.

Application Scenarios & Effect Demonstrations

Where H·EASY HY-1704/HY-2004 Excels

ensuring vibrant color reproduction and consistent heat transfer for sharp, durable, and high-quality sublimated prints.

Sublimation transfer paper for soft signage
Home décor
Apparel textiles—sampling to volume
Apparel textiles

H·EASY Technical Support

Through cooperation with world famous print head manufacturers and software suppliers, we integrate sophisticated and practical technology into our fabric printers.

One-Year Warranty (Extendable)

Standard 12-month coverage with optional 24/36-month extended care;

Installation & Onboarding

Step-by-step video and PDF guide for setup, calibration, and your first print.

Knowledge Base & Troubleshooting Docs

Quick guides for common issues with checklists and fixes.

Online Remote Guidance

Engineers provide real-time diagnosis and tuning via WhatsApp/Zoom/AnyDesk.

Frequently Asked Questions (FAQ)

Four I3200-A1 printheads in a CMYK setup.
1.6 m (HY-1704) / 1.9 m (HY-2004); maximum 3 mm media thickness.
HY-1704: 106 / 80 / 53 / 33 m²/h; HY-2004: 110 / 85 / 55 / 35 m²/h (2/3/4/6-pass).
720×1800 dpi; Gigabit Ethernet interface.
Sublimation ink with heated drying and cooling fans.
3 kW; refer to the table above for machine and packaging size and weight.
Print onto sublimation paper → heat transfer onto polyester fabric or sublimation-coated materials.
Adjust constant-tension feeding, roller pressure, and preheat temperature; keep the paper dry and flat.
Use a matching ICC profile; ensure ink circulation and nozzle health; increase passes or enable bi-directional compensation if needed.
Typically 185–205 °C for 40–60 s (adjust according to fabric type and transfer equipment TDS).
Before each shift: nozzle test. After each shift: clean and cap printheads; regularly clean rollers, guides, and heating zones; maintain environment at 20–25 °C and 50–60% RH.
Ensure proper ventilation and heat exhaust; handle high-temperature parts carefully; dispose of waste paper and ink according to local regulations.

15–25 days standard (custom 25–35). Packed with wooden crate + anti-shock + moisture protection. Sea/air/express available with full documentation.

Manuals/videos + remote commissioning for first prints & color setup; optional on-site install/training.

12-month machine warranty (printheads/consumables excluded). Factory parts support; post-warranty parts at factory price.

Yes—send your fabric or use ours. We return prints with recommended inks & pre/heat-fix parameters for fast ramp-up.

Available—per-call service and annual maintenance plans (inspection, calibration, consumables advisory).

Yes—we advise and connect pre-treat, steaming/washing/drying, heat-fix/set equipment for turnkey production.

HY-1704 / HY-2004 Specifications

SpecificationHY-1704 Sublimation PrinterHY-2004 Sublimation Printer
Print Head
Epson I3200 A1
Epson I3200 A1
Print Head Number
4
4
Print Mode
CMYK+CMYK+CMYK+CMYK
CMYK+CMYK+CMYK+CMYK
Print Width
1600 mm
1900 mm
Print Speed 2 pass
106 m2/h
110 m2/h
Print Speed 3 pass
80 m2/h
85 m2/h
Print Speed 4 pass
53 m2/h
55 m2/h
Print Speed 6 pass
33 m2/h
35 m2/h
Print Resolution
720x1800 dpi
720x1800 dpi
Media Type
Vinyl Flex banner Mesh One way vision Textile Wall paper Canvas Non woven fabric Photo paper PP Light sheet etc
Vinyl Flex banner Mesh One way vision Textile Wall paper Canvas Non woven fabric Photo paper PP Light sheet etc
Media Thickness
Max 3 mm
Max 3 mm
Ink Type
Sublimation ink
Sublimation ink
Curing System
Heating dryer plus cooling fan
Heating dryer plus cooling fan
File Format
BMP TIFF EPS PDF JPEG
BMP TIFF EPS PDF JPEG
RIP
Photoprint Onyx Caldera Colorgate Riin
Photoprint Onyx Caldera Colorgate Riin
Data Connector
Gigabit Ethernet
Gigabit Ethernet
Power
3 kW
3 kW
Machine Size L x W x H
2.78 m x 0.80 m x 1.57 m
3.45 m x 1.30 m x 1.57 m
Net Weight
280 kg
350 kg
Packing Size L x W x H
3.30 m x 0.85 m x 0.80 m
3.75 m x 1.50 m x 0.80 m
Gross Weight
310 kg
380 kg
Environment
Separated clean low dust well ventilated temperature 20-25 C humidity 50-60% non condensation
Separated clean low dust well ventilated temperature 20-25 C humidity 50-60% non condensation
