30 cm UV-DTF decals—compact printer for labels & transfers
HY-401 30UV UV-DTF Printer
Product Features & Benefits
Why Choose H·EASY HY-401 30 UV DTF
Industrial Epson I3200-U1HD
with multi-level grayscale for crisp details and smooth gradients in long runs.
CMYK+White+Varnish in one pass
build opaque white, rich color and spot/overall varnish without extra passes.
Compact 30 cm throughput
Compact 30 cm throughput for A4/A3 jobs; 0.76–2 m²/h depending on resolution and coverage.
Versatile media
Versatile media—UV-DTF A/B film, release film, soft roll materials; decals apply to phones, mugs, glass, metals, etc.
Stable Ink Supply & Network Connectivity
Smart inking & Ethernet connectivity, with common file formats supported.
Compact Size · Easy to Use & Maintain
Small footprint and simple operation; runs best at 20–28 °C / 35–65% RH.
UV Engine: I3200-U1HD · Multi-Gray Scale · High-Definition Output
• Equipped with 8 nozzle rows and 3,200 nozzles, enabling variable dot sizes for optimal detail and smooth color gradation.
• Resolution options: 960×1200 dpi / 960×900 dpi — allowing flexible balance between print speed and image quality.
• Printing thickness range: 0–1 mm, compatible with UV-DTF films and soft roll media with coated surfaces.
CMYK+W+V Printing · High Opacity White Base · Optional Varnish Layer
• Prints KCMY+W+V in a single pass — delivering non-transparent white layers, vivid colors, and optional varnish for spot or full coverage protection.
• One-pass layered printing reduces registration errors and rework, improving overall yield.
• Ideal for decals on glass, metal, ceramics, and phone cases — achieving enhanced texture and abrasion resistance when combined with varnish.
UV-DTF Workflow Friendly · Compact and Efficient Output
• Compatible with DTF A/B films and common release films; simply print → laminate with adhesive film (B film) → apply to the target surface to complete transfer.
• Printing speed range of 0.76–2 m²/h meets both sample proofing and small-batch production needs.
• Ethernet data transmission and support for standard file formats ensure smooth integration with existing design and output workflows
Application Scenarios & Effect Demonstrations
Where H·EASY UV DTF HY-401 30 Excels
delivering vivid, embossed prints with strong adhesion and versatile application on glass, metal, plastic, and more.
H·EASY Technical Support
Through cooperation with world famous print head manufacturers and software suppliers, we integrate sophisticated and practical technology into our fabric printers.
Frequently Asked Questions (FAQ)
HY-401 30 UV-DTF Printer Specifications
| Specification | HY-401 30 UV |
|---|---|
Print Head | EPSON I3200 U1HD x1 |
Print Head Ejection Force | 2-3 mm |
Nozzle Count | 3200 pcs |
Distance Between Nozzles | 1/300 inch |
Rows of Nozzles | 8 |
Max Ink Colors Supported | 8 |
Ink Drop & Freq 2-level | 5 pl at 43.2 kHz |
Ink Drop & Freq 3-level | 6.0-12.5 pl at 21.6 kHz |
Ink Drop & Freq 4-level | 3.8-6.2-9.3 pl at 21.6 kHz |
Printing Width | 30 cm |
Printing Depth | 0-1 mm |
Printing Pattern | White CMYK and Varnish simultaneous |
Printing Mode | KCMY+W+V |
Resolution | 960x1200 dpi / 960x900 dpi |
Net Weight | 75 kg |
Machine Size (L x W x H) | 919 mm x 980 mm x 450 mm |
Packaging Size (L x W x H) | 1.12 m x 1.12 m x 0.6 m |
Gross Weight | 100 kg |
Printing Software | Future RIP |
Applicable Materials | DTF AB film / release film / advertising soft roll materials |
Printing Speed Range | 0.76-7.2 m/h |
Text Format | TIF JPG EPS PDF |
Connection Mode | Network cable |
Power Supply & Voltage | AC 220 V ±10% 50/60 Hz |
Working Environment | Temperature 20-28 C Humidity 35-65% |
Ink Type | UV DTF special UV ink |
